Evology : Remote Control with 4 Functions / Scenarios - Product Sheet

**Prerequisite for installation and use:** * Enki application* + [Enki Box](https://support.enki-home.com/en/articles/17647644196626) **Additional Note:** *Prerequisite for Enki App: Internet access and a mobile with a minimum operating system: Android: 7 / iOS: 15* **Communication protocol:** * EnOcean **Available countries:** * France **Return status available:** * No **Alexa voice control:** * No **Google Home voice control:** * No **Article content:** * [Technical description](#01HRVPADX3SSJ60C3JD95PM1WX) * [Product functionality in the ENKI application](#01HRVPFJJNECVDSVHRXWGGA2ZJ) * [Product view](#01HRVPPSN5PAX419KGPNNQRNFW) * [How to reset my product](#01HRVPT202Y7X0GNV4BFA8G1H6) * [Technical documents / user manual](#h_01HRVRYTMGXH6RG9ZTWV063HD5) **Technical description:** * Type: Wireless remote control without battery * Requires Enki box: Yes / Enki Box V1 * Power supply: None, no battery or battery. Piezoelectric mechanism. * Magnetic-resistive power supply (without battery) * Protection rating: IP53 * Operating temperature: -10°C to 50°C * Radio protocol: EnOcean * Central radio frequency: 868.3 MHz * Frequency bands used: 868.0 to 868.6 MHz * Maximum radio power: +3 dBm * Signal range: 20-30 meters indoors * EEP (EnOcean® Profile): F6-02-02 * Weight: 76g * Dimension: 56 mm x 20 mm x 56 mm **Product functionality in the ENKI application:** | Object functionality | Properties | Integration into a scenario | |---|---|---| | Button + / Sun | Associate an action of a device or a scenario | ✘ | ✔ | - | | Button - / Moon | Associate an action of a device or a scenario | ✘ | ✔ | - | | Solid round button / Enter | Associate an action of a device or a scenario | ✘ | ✔ | - | | Empty round button / Exit | Associate an action of a device or a scenario | ✘ | ✔ | - | **Product view:** **How to reset my product?** **Technical documents / user manual**
