Prerequisites for installation and use :

• Enki Application* **+** Box Enki

* Prerequisite for the Enki application: Internet access and a phone with a minimum operating system: Android: 7 / iOS: 15



Communication protocol:

• Enocean

Available country:

• France

Status feedback available :

• No

Alexa voice command :

• No

Google Home voice command :

• No

Article content:

• Technical specifications

• Product features in the ENKI application

• Product view

• How do I reset my object?

• Technical documents / user manual





Technical specifications:

• Type: Battery-free connected remote control

• Requires the Enki box: Yes / ENKI Box V1

• Power supply: None, batteryless or battery operated. Piezoelectric mechanism.

• Power supply: magneto-resistive (batteryless)

• Protection index: IP53

• Operating temperature: 0°C to 40°C

• Radio protocol: EnOcean

• Central radio frequency: 868.3 MHz

• Frequency band used: 868.0 to 868.6 MHz

• Maximum radio power: +3 dBm

• Signal range: 20-30 meters indoors

• EEP (EnOcean® Profile): F6-02-02

• Weight: 76g

• Dimension: 56 mm x 20 mm x 56 mm



Product features in the ENKI application:

Object's functionality	Properties	Integration into a scenario
		Action	Condition
Plus button	Associate an action of equipment or a scenario	✘	✘
Minus button	Associate an action of equipment or a scenario	✘	✘
Full circular button	Associate an action of equipment or a scenario	✘	✘
Empty circular button	Associate an action of equipment or a scenario	✘	✘



Product view:



How to reset my device?







Technical documents / user manual
